Fence height

1.2m-3m

Fence width

2.75m (17 pales)

W Pale width

62mm, 68mm, 72mm

W Pale thickness

2-4mm

Top point

Three triple point

Angel rail

40x40x3mm

Post

IPE100x55mm
IPE120x74mm
SHS80x80x3.0mm
SHS100x100x4.0mm

Material

Cold and hot rolled steel belt

Surface treatment

Hot dipped galvanized

Accessories

Fish plate, HDG screw M8x25/M8x40/M12x40 and shear off nuts

Mesh Opening

50x100mm/50x150mm/50x200mm/55x200mm/75x150mm

Wire Diameter

3.0/3.5/4/4.5/5.0mm

Panel Height

0.6m-3.0m ( Suggest size : 2m/2.4m/3m )

Panel Width

2.0m-3.0m ( Suggest size : 2m/2.5m/2.9m )

Post Type

Round Post : 48x1.5/2.0mm 60x1.5/2.0mm

Square Post(SHS) : 50X50x1.5/2.0mm 60x60x1.5/2.0mm 80x80x1.5/2.0mm

Rectangular Post(RHS) : 40x60x1.5/2.0mm 40x80x1.5/2.0mm
60x80x1.5/2.0mm 80x100x1.5/2.0mm

Surface Treatment

hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating

Color

RAL 6005 green, RAL 7016 gray, All RAL color can be customized

Note

The fence can be customized according to your required if above specification is not satisfied with you
